HOSPITAL & MEDICAL INSTITUTES

ETO STERILIZER

FEATURES

Available in Fully S.S GMP Model & S.S/M.S Combination Standard Model
Chamber fabricated with heavy duty SS 304/ SS 316
Manufactured as per GMP norms.
Sterility assurance through automatic temperature control.
Accurate control of temperature, moisture, vacuum, valves and all critical parameters.
Touch Screen HMI & PLC based automation with 6 pre-programmed cycles & additional user defined cycles.
High Quality Temperature, Humidity, Pressure Sensors.
Hot and Cold sterilization cycles with possibility to set the temperature independently.
Vacuum Creation in the Chamber through Festo Branded Venturi System.
Automatic aeration cycle at the end of process for ETO exhaust.
Operates on universally available 100 grams ETO cartridge.
Live display of phase status, current values, set values, temperature, pressure & humidity.
Current & previous reports can be printed through internal printer.
ETO cartridge punctured only in negative pressure & humidity conditions.
Glass wool insulation.
Password protection to avoid unauthorized access.
Heat resistant Silicone door gasket for 100% Sealing.
Optional Steam Generator Provided with big capacity models
Energy Efficient Heating Coil made up of High-Quality Materials.
Low water protection system to protect the heating coils.
Audio alarm (Buzzer) gives signal of completion of sterilization cycle.
S.S 304 Quality Wire-mesh Basket provided with Every Model.
Optional Horizontal Band Sealing Machine available.

MODEL		ETO-55	ETO-75	ETO-85	ETO-125	ETO-225	ETO-250	ETO-290	ETO-450
Chamber Dim.MM	W	300 MM	300 MM	300 MM	300 MM	450 MM	450 MM	450 MM	600 MM
	H	300 MM	300 MM	300 MM	300 MM	450 MM	450 MM	450 MM	600 MM
	D	600 MM	750 MM	900 MM	1350 MM	1050 MM	1200 MM	1350 MM	1200 MM
Chamber Vol.	Lit.	55	75	85	125	225	250	290	450
Cu.ft		2.00	2.50	3.00	4.50	8.00	9.00	10.00	16.00
Power Single Phase	KW	2 KW	2 KW	2 KW	2 KW	3 KW	3 KW	4 KW	4 KW
