TISSUE CULTURE & MUSHROOM INDUSTRIES
BIOSAFTEY CABINET
FEATURES
- Hospharma Class 2 Biosafety Cabinets are designed to provide protection to operator, environment and materials inside the workspace. These Biosafety Cabinets are utilized for containing low-to-moderate risk biohazardous materials. These Biosafety Cabinets have downward airflow and HEPA filters that re-circulate air providing required level of protection from microorganisms and aerosols.
- Available in Vertical Model in Floor Standing & Table Top Model.
- Available in Fully S.S 304 GMP Model & S.S 304 / M.S Combination Standard Model.
- Available in CLASS 2 TYPE A2 & CLASS 2 TYPE B2 Cabinet.
- In CLASS 2 TYPE A2, approximately 70% of the HEPA filtered air is circulated through the cabinet, while 30% passes through an exhaust HEPA filter and is discharged.
- In CLASS 2 TYPE B2, no re-circulation inside workspace; blower exhausts 100% of the filtered air.
- Low Noise Level, High Airflow Capacity & Easy to Change Filters.
- Working Table/Chamber fabricated with heavy duty SS 304/ SS 316 Quality.
- Front Perforation Portion of 5” in size on the working table.
- Front Transparent Glass Door Available in all models with Vertical Sliding Shutter Type Mechanism.
- HEPA filtration unit provides Class 100 air quality with 99.999 % efficiency for particles >0.3 μm
- Pre-Filter provides 85 %efficiency for particles >0.5 μm (Cleanable)
- Inflow Velocity 95 to 105 fpm & Downflow Velocity 60 fpm.
- Blower Single Phase, 1440 RPM motor, Capacity 1000 CFM, Pressure 30 mm WG.
- High intensity, low wattage 750-800 lux Light & Noise Level Less than 65 decibels.
- We also offer number of optional features and accessories with Biosafety Cabinets such Microprocessor LCD Display Controller with timer, Vacuum Tap, Raised Air Flow Grill, Spare UV Lamp, Etc.
TABLE SPECIFICATIONS
| BIOSAFETY CABINET | |||||
|---|---|---|---|---|---|
| MODEL | BSC-2 | BSC-3 | BSC-4 | BSC-6 | |
| Work Table Dimension | H | 2 FEET | 2 FEET | 2 FEET | 2 FEET |
| W | 2 FEET | 2 FEET | 2 FEET | 2 FEET | |
| L | 2 FEET | 3 FEET | 4 FEET | 6 FEET | |
