LABORATORIES & PHARMACEUTICALS
LAMINAR AIR FLOWS
FEATURES
- Manufactured as per GMP norms.
- Hospharma Laminar air flow Cabinet consists of stainless-Steel Work table, Filter pad or pre-filter, HEPA Filter, Fan or blower, UV Lamp, Working stations fluorescent lamp etc. These important parts perform individual functions during its operation. The main function of laminar air flow is to remove all airborne contaminations for maintaining sterile conditions.
- Low Noise Level, High Airflow Capacity & Easy to Change Filters.
- Available in Horizontal & Vertical Models in Floor Standing & Table Top Model.
- Available in Fully S.S 304 GMP Model & S.S 304 / M.S Combination Standard Model
- Working Table/Chamber fabricated with heavy duty SS 304/ SS 316 Quality.
- Front Transparent Glass Door Available in all models with Hydraulic Hinge Door Opening or Vertical Sliding Door Mechanism.
- HEPA filtration unit provides Class 100 air quality with 99.999 % efficiency for particles >0.3 μm
- Pre-Filter provides 85 %efficiency for particles >0.5 μm (Cleanable)
- High efficient Blower centrifugal type with lifetime lubricated bearings.
- High intensity, low wattage 750-800 lux Light & Noise Level Less than 65 decibels.
- Branded Magnehelic Gauge or Differential Manometer available to check Filter Pressure.
- Auto switch on/off for U.V. Germicidal tube & fluorescent light along with Hour meter for UV light.
- Air/gas cock and mains power socket (16A) & Castor Wheels available in all the Floor Standing models.
- We also offer number of optional features and accessories with our Laminar Air Flow Cabinets such Microprocessor LCD Controller with timer & Digital display for air flow rate
TABLE SPECIFICATIONS
| HORIZONTAL LAMINAR AIR FLOW CABINET | ||||||
|---|---|---|---|---|---|---|
| MODEL | HLAF-2 | HLAF-3 | HLAF-4 | HLAF-6 | ||
| Work Table Dimension | H | 2 FEET | 2 FEET | 2 FEET | 2 FEET | |
| W | 2 FEET | 2 FEET | 2 FEET | 2 FEET | ||
| L | 2 FEET | 3 FEET | 4 FEET | 6 FEET | ||
| Size of Hepa Filter | 2 x 2 feet | 3 x 2 feet | 4 x 2 feet | 3 x 2 feet | ||
| No of Hepa Filters | 1 no | 1 no | 1 no | 2 nos | ||
| VERTICLE LAMINAR AIR FLOW CABINET | ||||||
|---|---|---|---|---|---|---|
| MODEL | VLAF-2 | VLAF-3 | VLAF-4 | VLAF-6 | ||
| Work Table Dimension | H | 2 FEET | 2 FEET | 2 FEET | 2 FEET | |
| W | 2 FEET | 2 FEET | 2 FEET | 2 FEET | ||
| L | 2 FEET | 3 FEET | 4 FEET | 6 FEET | ||
| Size of Hepa Filter | 2 x 2 feet | 3 x 2 feet | 4 x 2 feet | 3 x 2 feet | ||
| No of Hepa Filters | 1 no | 1 no | 1 no | 2 nos | ||
